The most capable compact caliper made! The F8X features billet, zero drag construction.

Designed for the demands of Pro stock Motorcycle racing, the F8 caliper has also found a home on go-karts and junior dragsters. Its compact design allows it to fit inside small diameter wheels while still providing great stopping power and Zero-Drag performance.

The TBM F8X Caliper Features:

• Billet high temperature aluminum outers for exceptional strength
• Black Hard Anodized Finish
• Compact and rigid to fit more places
• 4-piston design provides more clamping force and less drag.
• Single pad retention system
• 1.00” piston diameter
• Light weight – 1.16 lbs
• 2.50” mount width
• Maximum rotor thickness – .220”
• Pads available for all applications
• Available individually or in select brake kits.

Typical Applications: Pro Stock Motorcycle, Jr. Dragster, Mini Sprint.
